Exploiting a WPA2-EAP Wireless Network for Secure Access

---

Situation:

The goal of this exercise was to exploit a WPA2-EAP wireless network configured with TTLS and MSCHAPv2 protocols. The network artstailor-ddwrt-2 was targeted based on pod assignment, and the mission was to bypass the authentication mechanisms to gain access to a secure webpage hosted at 45.79.141.10.

---

Obstacles:

1. Authentication Challenge:
   • The WPA2-EAP network required credentials for TTLS authentication, which had to be intercepted and cracked.
2. File Configuration:
   • Properly configuring wpa_supplicant.conf with the necessary parameters for network access.
3. Dynamic Host Configuration Protocol (DHCP):
   • Establishing a valid IP address on the wlan0 interface after successful connection.

---

Actions Taken:

1. Wireless Channel Identification:
   • Ran sudo airmon-ng check kill to stop interfering processes.
   • Used sudo airmon-ng start wlan0 to enable monitor mode on the adapter, creating the wlan0mon interface.
   • Executed sudo airodump-ng wlan0mon to identify access points and their associated channels.
2. SSID Configuration:
   • Edited the hostapd-wpe.conf file to target the SSID artstailor-ddwrt-2.
   • Ran sudo ./hostapd-wpe hostapd-wpe.conf to capture NETNTLM credentials.
3. Password Cracking:
   • Created a password file and used john to crack the NETNTLM credentials, retrieving Sw0rdf1sh as the password.
4. Network Connection:
   • Configured wpa_supplicant.conf with the cracked credentials and appropriate authentication settings:
     • SSID: artstailor-ddwrt-2
     • Authentication: MSCHAPv2
   • Connected to the network using sudo wpa_supplicant -iwlan0 -cwpa_supplicant.conf.
5. DHCP Lease:
   • Obtained a valid IP address by running sudo dhclient wlan0.
   • Verified network connectivity using ip a.
6. Webpage Access:
   • Navigated to the webpage at http://45.79.141.10.
   • Inspected the source code and followed the hypertext link /Corp/message.txt to retrieve sensitive information.

---

Results:

1. Network Access Achieved:
   • Successfully authenticated to the WPA2-EAP network using the cracked credentials.
2. Data Retrieved:
   • Accessed sensitive information at /Corp/message.txt via the secure webpage.
3. Critical Vulnerability Identified:
   • Weak password configuration and lack of ca_cert validation exposed the network to unauthorized access.

---

Tool Purpose Overview:

airmon-ng:

• Enabled monitor mode on the wireless adapter to capture traffic.

airodump-ng:

• Identified wireless access points and associated channels.

hostapd-wpe:

• Captured NETNTLM credentials during the WPA2-EAP handshake.

john:

• Cracked NETNTLM credentials to retrieve the network password.

wpa_supplicant:

• Connected to the WPA2-EAP network using the cracked credentials.

---

Recommendations:

1. Enforce Stronger Password Policies:
   • Use complex passwords resistant to dictionary and brute-force attacks.
2. Implement Certificate Validation:
   • Require ca_cert validation in wpa_supplicant.conf to ensure secure authentication.
3. Monitor and Audit Wireless Networks:
   • Regularly test for vulnerabilities in wireless network configurations.
4. Enable Advanced Security Protocols:
   • Transition from MSCHAPv2 to a more secure EAP method, such as EAP-TLS.

---
